自有知識產權：納米級干法氣浮設備

高效納米干法氣浮系統由混合絮凝反應區、氣浮主體組成，其工作原理為：廢（污）水進入混合絮凝反應區后加入適當微量化學藥劑，該反應器獨有的內旋流反應方式能夠快速高效的使廢（污）水完成混合、絮凝、反應過程；絮凝后廢（污）水自流入氣浮主體。氣浮主體內特有的納米級微氣泡發生裝置，能夠在主體中產生100納米的微氣泡，微氣泡在氣浮分離區內形成1000~2000mm的微氣泡“海綿層”，污水自上而下通過“海綿層”，水體中懸浮物、藻類和膠體等物質被“海綿層”截留，形成浮渣停留在氣浮主體上表面，通過排渣機將浮渣刮走，清水則流過“海綿層”自底部清水收集裝置進入清水室，從而達到固液分離和凈化水體的功能。

高效納米級干法氣浮采用了納米微氣泡發生、次表面捕集、層流原理、等專有核心技術，能高效分離污水中的懸浮物。溶氣水、污水、藥劑三者在一個特別設計的多級序批式混凝反應器中，產生適合氣浮比重小于1的“夾氣泡絮體”，流入氣浮接觸區。在浮力的作用下，“泡絮體”上升至液面形成浮渣，完成固液分離。

Own intellectual property rights: nano-scale dry air flotation equipment

? ? ? ? ?The high-efficiency nano dry air flotation system consists of a mixed flocculation reaction zone and an air flotation main body. Its working principle is: after the waste (sewage) water enters the mixed flocculation reaction zone, appropriate trace chemicals are added. The reactor’s unique internal swirl reaction The method can quickly and efficiently complete the mixing, flocculation and reaction process of waste (sewage) water; after flocculation, the waste (sewage) water will flow into the main body of the air flotation. The unique nano-scale microbubble generating device in the air flotation main body can generate 100 nanometer microbubbles in the main body. The microbubbles form a 1000~2000mm microbubble “sponge layer” in the air flotation separation area, and the sewage passes from top to bottom. “Sponge layer”, suspended solids, algae, colloids and other substances in the water body are intercepted by the “sponge layer”, forming scum that stays on the upper surface of the air flotation body. The scum is scraped away by the slag discharge machine, and the clean water flows through the “sponge layer” “The clean water collection device at the bottom enters the clean water chamber, thereby achieving the functions of solid-liquid separation and water purification.

? ? ? ?High-efficiency nanoscale dry air flotation adopts proprietary core technologies such as nano-microbubble generation, sub-surface capture, and laminar flow principles, which can effectively separate suspended solids in sewage. Dissolved gas water, sewage, and chemicals are used in a specially designed multi-stage sequential batch coagulation reactor to produce “bubble-enclosed floc” suitable for air flotation with a specific gravity of less than 1, and flow into the air flotation contact area. Under the action of buoyancy, the “foamed floc” rises to the liquid surface to form scum, completing solid-liquid separation.
